1000W forced air cooled cPCI power supply

PCI-Systems, a supplier of conduction cooled systems,  announced a new 1000-W forced air cooled cPCI power supply.

Its key features include:

• 85-264 Vac Continuous Input Voltage

• 3000V Isolation Between Input /Output

• Active Input EMI Filtering

• Transient forward looking/cut-off technology

• 4 Voltage output Rails

• 1000 W Maximum Continuous Power

• 85% Typical Efficiency

• -10°C to 75°C Operating Temperature

• CompactPCI 8HP 6U Form Factor

• Active PFC input stage • 4 fans inside for low thermal deration

• SMART internal managing functions

This 6U power supply works with 85 to 265 Vac input and can be used for input frequencies from 47 to 63 Hz and isolates the input voltage ground from the output voltage ground.

The power supply is conduction cooled, uses polyphase technology on all voltage rails and can provide up to 1000 watts. It is suitable for use in mission critical rugged applications.
